Surface Mount VoIP Entry Phone

Model: E-20-IP

2 Amp relay contacts for door / gate or SL-2 Strobe Light control
SIP compliant
PoE powered (class 1, <4 Watts)
Automatic Noise Canceling (ANC) feature for proper operation in noisy environments
VoIP audio detection eliminates the need for “Push to Talk” mode
Handsfree operation
Chassis: Impact resistant, UV stable, light grey Geloy plastic with black UV stable pad printed graphics, surface mount only
Programmable to dial up to 5 numbers
Cycles through backup phone numbers on busy or ring-no-answer
Hangs up on busy signal, time-out or touch tone command
Programming software included
Network downloadable firmware
Remotely programmable
Diagnostics for testing mic, speaker, and relay
Extended temperature range: -40°F to 140°F (-40°C to 60°C)

View all features

Add to Pick List Added to Pick List

Software & Downloads

Product Manual

Quick Start Guide

IP Programming Software

E-IP Series Touch Tone Programming

VoIP SIP System Compatibility List

Facebook Tweet Pin LinkedIn Email

Questions?

We are here to help!

Product Details

The E-20-IP VoIP Entry Phone is designed to provide quick and reliable handsfree communication for SIP VoIP phone systems with PoE. The E-20-IP entry phone can be programmed from any touch tone phone, a PC on the same LAN, or remotely using a static IP address. The door entry phone can dial up to 5 programmable numbers.

All programming parameters, including phone numbers, are stored in non-volatile memory, requiring no batteries. This unit is PoE powered.

For outdoor installations where the unit is exposed to precipitation or condensation, use model E-20-IP-EWP. For more information on Enhanced Weather Protection (EWP), click here.

Applications

Gate Entrance
Parking ramps / lots
ATM machines
Medical centers
Lobbies
Entryways
Stadiums
Convention centers
Public access areas

Features

2 Amp relay contacts for door / gate or SL-2 Strobe Light control
SIP compliant
PoE powered (class 1, <4 Watts)
Automatic Noise Canceling (ANC) feature for proper operation in noisy environments
VoIP audio detection eliminates the need for “Push to Talk” mode
Handsfree operation
Chassis: Impact resistant, UV stable, light grey Geloy plastic with black UV stable pad printed graphics, surface mount only
Programmable to dial up to 5 numbers
Cycles through backup phone numbers on busy or ring-no-answer
Hangs up on busy signal, time-out or touch tone command
Programming software included
Network downloadable firmware
Remotely programmable
Diagnostics for testing mic, speaker, and relay
Extended temperature range: -40°F to 140°F (-40°C to 60°C)

Certifications

CE
Canada ICES
FCC Part 15
SIP

Specifications

Power: PoE class 1 (<4 Watts)
Maximum Sound Pressure: 90dB SPL @ 1m
Dimensions: 5.5″ x 4.5″ x 1.5″ (140mm x 115mm x 38mm)
Shipping Weight: 1.5 lbs (0.75 kg)
Operating Temperature: -40°F to 140°F (-40°C to 60°C)
Humidity: 5% to 95% non-condensing
Material: Impact resistant, UV stable, light grey Geloy plastic
SPDT Relay Contact Rating: 2A @ 30VDC / 1A @ 125VAC, 250VAC maximum
Audio Codecs: G711u, G711a, G722
Network Compliance: IEEE 802.3 af PoE, SIP 2.0 RFC3261, 100BASE-TX with auto cross over
Connections: (1) RJ45 10/100 Base-T, (3) gel-filled butt connectors
